150-mm G1 & G2 Mold Assembly

Part # AFG1M15 (includes a base plate)



Available Factory Direct

Email us for a quote


The picture shows the mold base plate upside down.

Use the 150-mm G1 and G2 Mold Assembly to make 150-mm specimens with Pine’s G1 and G2 Superpave Gyratory Compactors.

Specifications:  Meets the requirements of AASHTO T312 and ASTM D6925.

Height Available for Material:  252 mm

Inside Diameter:  150.0mm +0.0/-0.1 mm

Test Specimens:  These mold assemblies have sufficient capacity to produce standard Superpave specimens and tall performance test specimens.

Learn more about the mold base plate and how to use it correctly.
